What is a Spring pin connector?

A spring pin connector is a connector that consists of pins, tubes, and springs. Since the spring is contained in the tube connected to the pin, it is strong against vibration and has a structure that does not easily cause contact failure even if there is shaking. There are many types such as fine pitch connectors, low resistance modular connectors, and with housings, and the number of poles, number of contacts, contact height, etc. are abundant, and it is compatible with a wide range of applications. It has good durability, and some can be attached and detached with a single touch.

Application of Spring pin connector

Spring pin connectors are resistant to vibration and are used in mobile and transportation equipment. It also contributes to miniaturization and is suitable for applications that connect boards to each other or between boards and batteries. It is also used for cradle and internal antenna connection. There are surface mount type, through hole type, and solder cup type, which are connected to the board with solder. Spring pin connectors also have a wide range of shapes, such as a vertically bent connector and a low-profile type for signal connection, and are compatible with a variety of applications.
